Klimaprøvelokale

Feutron 3702/06

Feutron
Type: 3702/06
Climate Test Chamber, Water-cooled
Technical Data:
Test Chamber Nominal Volume: 2.0 m³
Dimensions: Outer chamber, with humidifier console
Width 2970 mm, Height 2370 mm, Depth 1530 mm
Rear Panel
Minimum installation dimensions: Width 2970 mm, Height 2390 mm, Depth 1550 mm
Test Space: Width 2000 mm, Height 1000 mm, Depth 1000 mm
Door: Double-leaf, Clear opening width 2000 mm, Height 1000 mm
Viewing Windows: Heated, 2 pcs, Width 500 mm, Height 600 mm
Access Port: 1 pc, left side wall, ∅ 75 mm
Temperature Range: -40...100°C
Climatic Range: 10...95°C
Temperature Variation Over Time: ≤ ± 0.5...± 1.0 ΔN/K
Change Rates measured at air supply without load
Cooling up to average 2.0 K/min
Heating up to average 2.0 K/min
Humidity Range: 10...95% r.h.
Humidity Variation Over Time: ≤ ± 3.0% r.h.
Dew Point Range, temporarily up to -5...95°C
Refrigeration System: water-cooled, semi-hermetic Bitzer unit
Refrigerant: R507 (Μ-Κ1)
Climate and Dryer Refrigeration Unit air-cooled /hermetic system
Refrigerant: R134a (Μ.ΚΚ)
Power Supply:
Electrical Connection: 400V 3/N/PE.AC, 50Hz
Mains Plug: CEE 5-pin, 32 A, with 5.0 m cable
Max. Simultaneous Power Demand: 10.0 kW
Supply Line Fuse: 3x 25A characteristic C
Degree of Protection: IP20
Weight: 1300 kg
Condition: used
Gkodpfok E Hnqsx Ah Sjd
Scope of Delivery: (See picture)
(Subject to changes and errors in technical data and information!)
For further inquiries, feel free to contact us by phone.
